Gainward GeForce GTX 1060 6GB Phoenix GS

Varenummer: 895105 / Produktnr.: 426018336-3736

Flere bilder av

GeForce GTX 1060 grafikkort er lastet med innovative nye spillteknologier, slik at det er det perfekte valget for de nyeste high-definition-spillene. Drevet av NVIDIA Pascal™ – den mest avanserte GPU-arkitekturen som noensinne er opprettet – GeForce GTX 1060 yter briljant ytelse som åpner døren til virtual reality og mer. #GameReady.

GAINWARD GeForce GTX 1060 6GB PHOENIX “Golden Sample”

Fullwidth media container description

Gainward’s Expertool II

The brand-new utility adds flexible fan curve control and BIOS saving feature for powerful GeForce GTX 1060 card.

Key Features

  • NVIDIA Pascal architecture , 6GB GDDR5 memory
  • NVIDIA GPU Boost 3.0
  • 16nm FinFET process
  • NVIDIA Ansel technology
  • Simultaneous Multi-Projection
  • NVIDIA GameWorks technology
  • NVIDIA VRWorks technology
  • NVIDIA Adaptive Vertical Sync
  • NVIDIA G-SYNC ready
  • Microsoft DirectX 12 support
  • NVIDIA PhysX technology
  • Vulkan API support
  • PCI Express 3.0 support
  • OpenGL 4.5 and OpenCL support
  • 1* Dual-link DVI, 1* HDMI (v2.0), 3* DisplayPort (v1.3/1.4 ready)

Gainward superior hardware design

Gainward re-designs the entire hardware, that brings higher stability under high current operation (heavy loading operation).

DrMOS

DrMOS is designed to handle high current with low noise operation and less heat generating.

Dual BIOS (1: OC, 2: standard)

Gainward provides two VBIOS for GeForce GTX 1060 Phoenix board. Factory over-clocking VBIOS is set on position 1 of the “dual BIOS switch” . Users can overclocking the Phoenix board with confidence thanks to the “standard-clock setting” in the second VBIOS with position 2 of the “dual BIOS switch” whenever you need.

Extreme silent acoustics in heavy loading mode

Gainward GeForce GTX 1060 Phoenix “GS” with factory over-clocked speed gets much quieter than founders edition board under full load operation.

Extreme cool temperature in heavy loading mode

Gainward GeForce GTX 1060 Phoenix “GS” with factory over-clocked speed performs extremely lower GPU temperature than founders edition board with reference clock.

Fullwidth media container description
Generelt
Garanti (måneder) 36
Enhetstype Grafikkort
Busstype PCI Express 3.0 x16
Grafikkprogram NVIDIA GeForce GTX 1060
Kjerneklokke 1620 MHz
Boost Clock 1847 MHz
CUDA-kjerner 1280
Prosessteknologi 16 nm
VR-klar Ja
Maks. oppløsning 4096 x 2160 ved 60 Hz
Maks oppløsningsdetaljer DVI: 2560 x 1600 / DisplayPort: 4096 x 2160 / HDMI: 4096 x 2160
Grensesnitt DVI-D (dobbeltlenke)
HDMI
3 x DisplayPort
Støttede API OpenCL, DirectX 12, OpenGL 4.5, Vulkan
Egenskaper Dual Bios, Nvidia PhysX-Ready, Nvidia 3D Vision Surround Ready, 2.5-slot Fan Cooler, NVIDIA Adaptive Vertical Sync, UEFI BIOS, klar for NVIDIA G-Sync, fabrikktestet med høyere klokkerate, NVIDIA GameWorks, DrMOS, Nvidia GeForce GTX VR Ready, NVIDIA GPU Boost 3.0, NVIDIA Ansel, HDCP
Minne
Størrelse 6 GB
Teknologi GDDR5 SDRAM
Faktisk klokkehastighet 4 GHz
Bussbredde 192-bit
Båndbredde 192 GBps
Systemkrav
OS påkrevd Microsoft Windows 7 / 8 / 10
Påkrevd strømforsyning 400 W
Ekstrakrav Dobbeltbredde x16-grafikkspor, 6-pins PCI Express-strømkontakt
Diverse
Tilleggsutstyr inkludert 6-pins PCIe-strømkabel
Inkludert programvare Displaydrivere, Gainward Expertool II
Dybde 24.8 cm
Høyde 12.3 cm
