Gigabyte GA-Z97X-UD5H-BK, Socket-1150

Varenummer: 815543 / Produktnr.: GA-Z97X-UD5H-BK

Flere bilder av

  • Extended server level 168 hour durability Test
  • Supports 4th and 5th Generation Intel® Core™ processors
  • Extreme multi graphics support
  • Precise digital CPU power design
  • SATA Express support for 10 Gb/s data transfer
  • M.2 for SSDs drives with up to 10 Gb/s data transfer
  • Killer™ E2200 and Intel gaming networking
  • Realtek ALC1150 115dB SNR HD Audio with built-in rear audio amplifier
  • 2x copper PCB design
  • Long lifespan Durable Black Solid caps
  • APP Center including EasyTune™ and Cloud Station™ utilities
  • GIGABYTE UEFI DualBIOS™
  • Extended server level 168 hour Durability Test

    GIGABYTE Black Edition motherboards undergo an extra 168 hours (7 days) of stress testing before shipment to ensure premium quality for our customers. During the 168 hour test, each motherboard needs to pass rigorous, full system validation testing for 1 full week. GIGABYTE has built a custom testing facility at our Taiwan (Nanping) factory. A Certificate of Validation is included with every board, issued by the GIGABYTE factory and signed by the manufacturing VP & GM to indicate that each board has passed our highest test standards.

    GIGABYTE 9 Series Motherboards
    GIGABYTE 9 Series motherboards support the latest 4th & 5th Generation Intel® Core™ processors, bringing together a unique blend of features and technologies that offer the absolute ultimate platform for your next PC build.
    Extreme Multi-GPU Support
    Flexible graphics capabilities supported for either 3-Way CrossFire™ or 2-Way SLI™ action, delivering the ultimate in graphics performance for gaming enthusiasts who demand the highest frame rates without compromising on resolution.
    M.2 Onboard Connector
    GIGABYTE 9 series motherboards come equipped with an onboard M.2 slot, providing users PCI-Express connectivity for SSD devices. Delivering up to 10 Gb/s data transfer speeds, M.2 offers users considerably faster storage performance than current mSATA and even SATA Revision 3 (6Gb/s) storage devices.
    SATA Express Connector
    SATA Express interface provides multiple PCI Express lanes and 2 SATA 3.0 6 Gb/s ports, exposed through the same connector, allowing use of both PCI Express and SATA storage devices. Exposed PCI Express lanes are providing a pure PCI Express connection to the storage device, without any additional layers of abstraction.
    Intel ® Gigabit LAN
    Intel® Gigabit LAN networking, a popular choice with gamers that features several performance-enhancing features such as advanced interrupt handling to help reduce CPU overhead and Jumbo Frame support for extra large data packets.
    Killer Networking
    NO LAG, JUST FRAG!
    Select GIGABYTE 9 series motherboards feature the Killer™ E2200 from Qualcomm Atheros, a high-performance, adaptive gigabit Ethernet controller that offers better online gaming and online media performance compared to standard solutions. The Killer™ E2200 features Advanced Stream Detect technology, which identifies and prioritizes all network traffic to ensure important applications that require high-speed connectivity are prioritized over less important traffic.
    Realtek ALC1150 115dB SNR HD Audio
    The ALC1150 is a high-performance multi-channel High Definition Audio Codec that delivers an exceptional audio listening experience with up to 115dB SNR, ensuring users get the best possible audio quality from their PC.

    The ALC1150 provides ten DAC channels that simultaneously support 7.1-channel sound playback, plus 2 channels of independent stereo sound output (multiple streaming) through the front panel stereo outputs. Two stereo ADCs are integrated and can support a microphone array with Acoustic Echo Cancellation (AEC), Beam Forming (BF), and Noise Suppression (NS) technologies. The ALC1150 incorporates Realtek proprietary converter technology to achieve Front differential output 115dB Signal-to-Noise ratio (SNR) playback (DAC) quality and 104dB SNR recording (ADC) quality.
    Built-in Rear Audio Amplifier
    Specially designed for gamers, GIGABYTE 9 series Ultra Durable™ motherboards utilize a high-capacity amplifier which is able to drive 600O loads, giving gamers a fuller range of dynamic sound with crisper details and less distortion when using high quality professional headphones.

    All New Heat Sink Design

    Generelt
    Garanti (måneder) 36
    Produkttype Hovedkort - ATX
    Brikkesett type Intel Z97 Express
    Prosessorsokkel LGA1150-sokkel
    Maks antall prosessorer 1
    Kompatible prosessorer Pentium, Celeron, Core i5, Core i3, Core i7
    Støttet RAM
    Maks størrelse 32 GB
    Teknologi DDR3
    Bussklokke 1600 MHz, 1333 MHz, 2800 MHz (O.C.), 2933 MHz (O.C.), 2666 MHz (O.C.), 2600 MHz (O.C.), 2500 MHz (O.C.), 2400 MHz (O.C.), 2200 MHz (O.C.), 2133 MHz (O.C.), 2000 MHz (O.C.), 1866 MHz (O.C.), 1800 MHz (O.C.), 3000 MHz (O.C.)
    Støttet RAM-integritetskontroll Ikke-ECC
    Egenskaper Dobbeltkanalsminnearkitektur, Intel Extreme Memory Profiles (XMP)
    Grafikk
    Maks allokert RAM-størrelse 1 GB
    Lyd
    Type HD-lyd (8-kanalers)
    Audio Codec Realtek ALC1150
    Tilpassede standarder High Definition Audio
    LAN
    Nettverksgrensesnitt 2 x Gigabit Ethernet
    Ekspansjon / Tilkoplinger
    Utvidelsesspor 1 x CPU
    4 x 240-pins DIMM
    1 x PCIe 3.0 x16 (x16-modus (x8-modus hvis nabospor er besatt))
    1 x PCIe 3.0 x16 (x8-modus (x4-modus hvis nabostasjonen er opptatt))
    1 x PCIe 3.0 x16 (x4-modus)
    2 x PCIe 2.0 x1
    2 x PCI
    Lagergrensesnitt SATA-600 -kontakter: 6 x 7pin SATA, 1 x M.2, 1 x SATA Express port - 6 enheter - RAID 0 / RAID 1 / RAID 10 / RAID 5
    Marvell 88SE9172: SATA-600 -kontakter: 2 x 7-pin seriell ATA - 2 enheter - RAID 0 / RAID 1
    RAID-funksjoner Intel Smart Response Technology
    Grensesnitt 2 x LAN (Gigabit Ethernet)
    2 x USB 2.0
    1 x HDMI
    6 x USB 3.0
    1 x VGA
    1 x lydutlinje - minijakk
    1 x lydinnlinje - minijakk
    1 x mikrofon - minijakk
    1 x lydutlinje (bakre) - minijakk
    1 x lydutlinje (senter/subbasshøyttaler) - minijakk
    1 x TOSLINK
    1 x PS/2-tastatur / -mus
    1 x DVI-D
    Interne overflater 4 x USB 2.0 - header
    2 x USB 3.0 - header
    1 x lyd - header
    1 x SPDIF-utgang - header
    1 x seriell - header
    Strømkontakter 24-pin hovedstrømforsyningskontakt, 8-pin ATX12V-kontakt
    Egenskaper
    BIOS Type AMI
    BIOS-egenskaper WfM 2.0 støttet, UEFI BIOS, SMBIOS 2.7-støtte, DMI 2.7-støtte, ACPI 5.0-støtte, Dual BIOS
    Overvåking av maskinvare CPU-kjernetemperatur, chassis-temperatur, viftehastighet for CPU, viftehastighet for chassis, systemspenning, CPU overopphetingsbeskyttelse
    Maskinvarefunksjoner Q-Flash, Intel Extreme Memory Profile (XMP)-støtte, NVIDIA 2-way SLI Technology Support, On/Off Charge, Intel Smart Response Technology, Fanless Design Heatsink, Ultra Durable, AMD CrossFireX-teknologistøtte, AMD 3-veis CrossFireX-teknologistøtte, Intel Rapid Start Technology, Intel Smart Connect Technology, ESD Protection, GIGABYTE OPT Fan Support, Black Solid Capacitors, GIGABYTE Smart Switch
    Diverse
    Inkludert programvare Norton Internet Security, @BIOS, EasyTune, Cloud Station, GIGABYTE EZ Setup, Xpress Install, GIGABYTE USB Blocker, GIGABYTE App Center, Smart TimeLock, GIGABYTE Fast Boot
    Tilpassede standarder Plug and Play, ACPI 5.0
    Bredde 30.5 cm
    Dybde 24.4 cm
