ASUS B85M-G, S-1150, PC-PROD RESERVEDEL

Varenummer: 782480 / Produktnr.: B85M-G

Flere bilder av

Micro-ATX B85 features high-endurance 5X Protection and new UEFI BIOS

  • ASUS 5X Protection: All-round protection provides the best quality, reliability, and durability
  • USB 3.0 BOOST (UASP Support): 170% faster transfer speeds than traditional USB 3.0
  • Network iControl: Real-time network bandwidth management
  • Fan Xpert :Dedicated CPU and case fan controls
  • CrashFree BIOS 3: Restore corrupted BIOS data from USB storage
  • AI Suite 3: One-stop access to innovative ASUS features

ASUS 5X Protection

All-round protection provides the best quality, reliability, and durability

ASUS motherboards guard your PC with 5X Protection. We use quality components like DIGI+ VRM digital power design for precise CPU power on demand, ESD units tested to strict standards that eliminate electrostatic interference, and resettable fuses around DRAM slots to prevent overcurrent and short-circuit damage. We also use corrosion-resistant back I/O shields, all examples of ASUS providing the best possible reliability and durability.

New UEFI BIOS – friendlier and more Intuitive

Exclusive EZ Mode adds useful info to become even easier

Media-renowned UEFI BIOS from ASUS provides the smoothest mouse-controlled graphical BIOS, and now features more intuitive functions to quickly take you to favorite BIOS pages and frequently-accessed settings through custom shortcuts. You can even write quick notes in-BIOS for future reference, view an activity log of setting changes and modifications, and rename SATA ports. EZ Mode has a whole new look, upgraded with extra-friendly capabilities like detailed fan controls, XMP profile settings, SATA information, and fast clock adjustment. Together, these perfect your BIOS experience.

4K Ultra HD ready

Discover future visual experiences

Following up on popular 1080p full HD, 4K Ultra HD is the next big thing, and you’re ready for the upgrade thanks to integrated graphics that natively support up to 4096 x 2160 via HDMI or DisplayPort. That’s four times the pixel count of 1080p (1920 x 1080), offering incredible visual clarity, detail, and realism.

USB 3.0 Boost (UASP Support)

170% faster transfer speeds than traditional USB 3.0

ASUS USB 3.0 Boost technology supports UASP (USB Attached SCSI Protocol) in Windows 8. With USB 3.0 Boost technology, a USB device's transmission speed is significantly increased up to 170%, adding to already fast USB 3.0 performance. ASUS software automatically accelerates data rates for compatible USB 3.0 peripherals without any user interaction

  • World’s 1st USB 3.0 UASP support – instantly 170% faster.
  • Complete USB 3.0 solution – performance boost under Turbo Mode or UASP Mode for most USB devices.
  • Simple plug and boost – auto detection design ensures best performance.

Q-DIMM

Easy memory removal

Even if you work with a smaller case, plugging in memory is easy with one-sided clips that are right at the edge of the board and always accessible. Just push down on the clip and push or pull RAM modules in or out – couldn’t be simpler!

AI Suite 3

One-stop access to innovative ASUS features

ASUS AI Suite 3 offers a brand new user experience through a clearer and more attractive interface with support for larger monitors. It consolidates all exclusive ASUS features into one simple-to-use package, allowing you to supervise overclocking, energy consumption, fan speeds, voltages and more. This all-in-one app offers diverse and easy to use functionality, with no need to switch back and forth between different utilities.

Included:

  • User manualg
  • I/O-shield
  • 2 x SATA 6Gb/s-cable(cables)
Generelt
Garanti (måneder) 36
Produkttype Hovedkort - mikro ATX
Brikkesett type Intel B85 Express
Prosessorsokkel LGA1150-sokkel
Maks antall prosessorer 1
Kompatible prosessorer Pentium, Celeron, Core i5, Core i3, Core i7
Støttet RAM
Maks størrelse 32 GB
Teknologi DDR3
Bussklokke 1600 MHz, 1333 MHz, 1066 MHz
Støttet RAM-integritetskontroll Ikke-ECC
Registrert eller bufret Ikke-bufret
Egenskaper Dobbeltkanalsminnearkitektur
Grafikk
Maks allokert RAM-størrelse 1024 MB
Lyd
Type HD-lyd (8-kanalers)
Audio Codec Realtek ALC887-VD2
Tilpassede standarder High Definition Audio
LAN
Nettverkskontroller Realtek RTL8111G
Nettverksgrensesnitt Gigabit Ethernet
Ekspansjon / Tilkoplinger
Utvidelsesspor 1 x CPU
4 x 240-pins DIMM
1 x PCIe 3.0 x16
2 x PCIe 2.0 x1
Lagergrensesnitt SATA-600 -kontakter: 4 x 7-pin seriell ATA - 4 enheter
SATA-300 -kontakter: 2 x 7-pin seriell ATA - 2 enheter
Grensesnitt 1 x PS/2-tastatur
1 x PS/2-mus
2 x USB 3.0
1 x LAN (Gigabit Ethernet)
1 x VGA
1 x DVI-D
1 x HDMI
4 x USB 2.0
1 x lydinnlinje - mini-jack
1 x mikrofon - mini-jack
1 x lydutlinje - mini-jack
Interne overflater 4 x USB 2.0 - header
2 x USB 3.0 - header
1 x SPDIF-utgang - header
1 x lyd - header
1 x seriell - header
1 x parallell - header
Strømkontakter 4-pin ATX12V-kontakt, 24-pin hovedstrømforsyningskontakt
Egenskaper
BIOS Type AMI
BIOS-egenskaper DMI 2.0-støtte, WfM 2.0 støttet, flerispråklig BIOS, ASUS MyLogo2, ASUS Quiet Thermal Solution, ASUS EZ Flash 2, ACPI 2.0a-støtte, UEFI BIOS, SMBIOS 2.7-støtte
Sov/Våkne Wake on LAN (WOL), Wake on Ring (WOR)
Maskinvarefunksjoner Jakk-retasking, ASUS Anti-Surge Protection, ASUS Q-Design, ESD Guards, Q-DIMM, GPU Boost, ASUS EZ DIY, Q-Slot, CrashFree BIOS 3, All-Solid Capacitor motherboard Design, lydjakkpåvisningsteknologi, ASUS EPU (Energy Processing Unit), ASUS Fan Xpert, Intel Turbo Boost Technology 2.0, ASUS DIGI+ VRM, ASUS USB 3.0 Boost-teknologi, ASUS Network iControl, ASUS 5X PROTECTION, 4K Ultra HD klar
Diverse
Tilleggsutstyr inkludert I/O-bakplate
Medfølgende kabler 2 x Seriell ATA-kabel
Inkludert programvare Drivers & Utilities, ASUS EZ Flash 2, ASUS AI Charger, ASUS Update, ASUS AI Suite III
Kompatibel med Windows 7 "Kompatibel med Windows 7" software og enheter er en forsikring fra Microsoft om at disse produktene har bestått prøver mht kompatibilitet og driftssikkerhet med 32-bits og 64-bits Windows 7.
Tilpassede standarder Plug and Play, ACPI 2.0a, ErP Ready
Bredde 23.3 cm
Dybde 19.3 cm
