Denne varen finnes ikke lenger i vårt sortiment, men kontakt oss gjerne på 33 00 55 00 eller kundeservice@komplett.no så hjelper vi deg finne et alternativt produkt til dette.
SAPPHIRE NITRO+ & PULSE AMD Radeon™ RX 7700 Series are designed with digital power which provides accurate power control and excellent power efficiency
Ultra High Performance Conductive Polymer Aluminum Capacitor
The Ultra High Performance Conductive Polymer Aluminum Capacitor has a small PCB foot print but high volumetric capacitance that makes 14-phase power possible on the RX 7700 series graphics card. The capacitor offers stable capacitance at a high frequency and temperature with very low signal noise, ensuring the stability and reliability of the product.
High TG Copper PCB
The GPU is mounted on to the high-density 14 layer 2oz Copper and high TG PCB to match the rapid speed, high current and increased power requirement of the GPU and memory to guarantee high stability of the PCB during operation.
Angular Velocity Fan Blade
The Angular Velocity Fan Blade provides a double layer of downward air pressure which alongside the air pressure on the outer ring of the Axial fan, results in up to 44% more downward air pressure and up to 19% more airflow for a quieter and cooler operation when compared to the previous generations.
Optimized Composite Heatpipe
The composite heatpipes are fine-tuned for each individual cooling design with optimal heat flow, efficiently and evenly spreading out the heat to the entire cooling module.
Fuse Protection
In order to protect your card, the SAPPHIRE cards have fuse protection built into the circuit of the external PCI-E power connector to keep the components safe.
Two-Ball Bearing
These feature Dual Ball bearing fans, which have an approximately 85% longer lifespan than sleeve bearings in our tests. The improvements to the fan blades means the solution is up to 10% quieter than the previous generation.
Generelt
Produktserie
Sapphire Pulse Radeon
Modell
RX 7600
Garanti (måneder)
36
EAN
4895106293618
Videoutgang
Type
Grafikkort
Støttede API
DirectX 12 Ultimate
VR-klar
Ja
Grafikkprosessorfabrikant
AMD
Maks ekstern oppløsning
7680 x 4320
Grensesnittype
PCI Express 4.0 x8
Antall strømningsprosessorer
2048
Grafikkprosessor
AMD Radeon RX 7600
Maks antall skjermer
4
Klokkehastighetsøkning
2755 MHz
Utgangsporter (kompakt liste)
3 x DisplayPort, HDMI
Videoadapterfunksjoner
UEFI BIOS, Game Driver Optimizations, RDNA 3 Gaming Architecture, Bakplate i aluminium, AMD Radeon Anti Lag Technology, Sapphire Dual-X Cooling Technology, AMD FidelityFX Super Resolution 2 (FSR), Precision Fan Control, 2-slot Fan Cooler, Sikringsvern, TriXX Boost, Radeon Image Sharpening, 32 regneenheter, AMD Smart Access Memory-teknologi, Intelligent Fan Control (IFC), Dual Fan Design, Komposittvarmerør, Dual ball Bearing Fans, TriXX Supported, AMD Radeon Boost Technology, AMD VR Ready Premium, AMD Infinity Cache, FreeSync Technology, 32 Ray Accelerators, Video Streaming inntil 8 K, AMD Radeon Super Resolution (RSR)
Støttet videosignal
DisplayPort, HDMI
Videominne
Bussbredde
128-bit
Installert størrelse
8 GB
Minnehastighet
18 Gbps
Teknologi
GDDR6 SDRAM
Strømenhet
Strømforbruk ved drift
185 watt
Systemkrav
Min. RAM-størrelse
8 GB
Ekstrakrav
8-pins PCI Express-strømkontakt
Påkrevd strømforsyning
550 W
OS påkrevd
Linux (64-bits), Windows 11, Windows 10 (64-bit)
Diverse
Tilpassede standarder
DisplayPort 1.4
Fargekategori
Svart, Rød
Størrelser og vekt
Bredde
4.407 cm
Dybde
24 cm
Høyde
10.71 cm
Grensesnittdetaljer
Grensesnittdetaljer
HDMI, 3 x DisplayPort (Display Stream Compression (DSC))
