ZOTAC ZBOX Magnus EN1080K
i7-7700, GeForce® GTX 1080, VR-ready, 802.11ac, DDR4, USB3.1, 3x HDMI, 2x DP
Av
ZOTAC
Varenummer:
921421
/ Produktnr.:
ZBOX-EN1080K-BE
Produktinfo
ZOTAC ZBOX Magnus EN1080K
THE NUMBER 1 GAMING MINI PC
MAGNUS is the Number 1 in gaming Mini PC in size to performance ratio. There are no others like it. Nothing as small, nothing as lightweight, nothing as powerful, nothing as connection filled, nothing as quiet, and nothing as cool. This is the ultimate gaming PC. Period.
THE SMALLEST VR READY MINI PC
MAGNUS comes packed with more power and speed than ever with performance on par with even some desktops many times the size. Get equipped with MAGNUS and power your play to the next level with the HTC Vive*, Oculus Rift*, or other PC compatible VR headsets.
*sold separately
*sold separately


INTEL KABY LAKE
Built on 14nm manufacturing process, the quad-core processor delivers breakthroughs in performance and power efficiency for quick responsiveness

DDR4 MEMORY
Lower voltage, faster speeds, and more total memory capacity

PCIE X4 / SATA M.2 SUPPORT
Wide super highway data lanes enable support for NVMe PCIe x4 M.2 SSD

USB 3.1 GEN2
Doubling previous USB speeds for up to 10Gbps throughput bring easy fast transfers

HDMI 2.0
Fluid viewing with 4K resolution at 60 Hz for life-like motion

DISPLAYPORT 1.3
Future display ready for 4K and beyond…up to a vision clearing 8K resolution

NVIDIA G-SYNC™ READY
Pair with a compatible display for ultra-smooth gameplay

DRIVE UP TO 4 DISPLAYS
Get the advantage and see more and show more
THE MOST POWERFUL MINI PC
The MAGNUS EN1080K delivers performance of the highest caliber with a 7th generation Intel Kaby Lake processor and NVIDIA GeForce® GTX 1080 graphics. This is the power of an immense tall desktop computer packed into the most compact size.
WHISPER QUIET, MAXIMUM COOLING
There is almost always a trade-off between performance, thermals, and noise when it comes to Mini PCs. Our engineers pushed the cooling hardware to the limits, carefully fine tuning the balance to extract maximum everything. The MAGNUS EN1080 is equipped with a specially designed liquid cooling thermal system that keep both GPU and CPU in check so it can go full force.

Spesifikasjoner
Garanti (måneder) | 24 |
---|---|
Type | Barebone-PC |
Produktformfaktor | Mini-PC |
Innebygde enheter | Væskeavkjølingssystem |
CPU | Intel Core i7 (7. generasjon) 7700 / 3.6 GHz |
---|---|
Max Turbo-hastighet | 4.2 GHz |
Antall kjerner | Firerkjerne |
Antall CPU-er | 1 |
Maks. antall CPU-er | 1 |
Prosessorhovedfunksjoner | Intel Turbo Boost Technology 2 |
Installert størrelse | 0 GB / 32 GB (maks.) |
---|---|
Teknologi | DDR4 SDRAM |
Produktformfaktor | SO DIMM 260-pin |
Spor | 2 (Total) / 2 (tomt) |
Type | Uten HDD |
---|
Type | 1 x SATA |
---|---|
Kontroller grensesnittype | SATA 6Gb/s |
Type | Ingen optisk drev |
---|
Type | 3 i 1-kortleser |
---|---|
Støttede flash-minnekort | SD-minnekort, SDHC-minnekort, SDXC-minnekort |
Skjermtype | Ingen. |
---|
Grafikkprosessor | NVIDIA GeForce GTX 1080 |
---|---|
Videominne | 8 GB GDDR5X SDRAM |
Videogrensesnitt | HDMI, DisplayPort |
HDCP-kompatibel | Ja |
Maks. antall skjermer som støttes | 4 |
Trådløs LAN-støtte | Ja |
---|---|
Datakjedeprotokoll | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11ac, Bluetooth 4.2 |
Brønner | 1 (total) / 1 (ledig) x intern 2.5" x 1/8H 1 (total) / 1 (ledig) x intern M.2 2242/2260/2280 |
---|---|
Spor | 2 (total) / 2 (ledig) x SO-DIMM 260-stifts 1 (total) / 0 (ledig) x CPU |
Grensesnitt | 2 x LAN (Gigabit Ethernet) - RJ-45 3 x HDMI (1 foran, 2 bak) 2 x DisplayPort 1 x USB-C 3.1 1 x USB 3.1 - Type A 4 x USB 3.0 - Type A 1 x mikrofon - mini-jack (1 foran) 1 x lydutlinje - mini-jack (1 foran) |
Tilleggsutstyr inkludert | 2x trådløs antenne |
---|---|
Vern mot tyveri/inntrenging | Sikkerhetslåsspor (kabellås selges separat) |
Enhetstype | Strømadapter |
---|
OS Medfølger | Uten operativsystem |
---|---|
Programvare | Drivers & Utilities |
Bredde | 20.3 cm |
---|---|
Dybde | 22.5 cm |
Høyde | 12.8 cm |
