ATEN MasterView CS1644A 4P DVI Dual Head
USB 2.0, audio, USB hub (m/ kabler)
Av
ATEN
Varenummer:
507549
/ Produktnr.:
CS1644A-AT-G
Ikke på lager. 6 stk. Ubekreftet 4.jul.2019
Produktinfo
ATEN CS1644A
4-Port USB DVI Dual Display KVMP™ Switch
The CS1644A 4-Port USB DVI Dual View KVMP™ Switch is a multi-application device that integrates a 4-port KVM switch with 2-port USB hub. The newest version now supports Quad-View functionality with two Dual View KVM Switches connected.
The new CS1644A features multi-view capabilities, which allow two switches to be daisy chained for a dual, triple, or quadview display across multi-monitor installations. The CS1644A supports advanced nVidia 3D Vision ready 120Hz 3D displaying,allowing you to manage various 3D visual effects. It allows you to manipulate all connected computers from a single console to save resources and work space. It enables each computer to access connected peripherals on a one-computer-at-a-time basis, making it ideal for users who need delicate visual effects and multi-tasking on several computers. The CS1644A is perfect for graphic designers, banking and financial consultants, gamers and medical professionals- demanding a high quality switch that provides stunning color, clarity and functionality.
- One dual-screen USB console controls two/four dual-screen computers and two additional USB devices
- Multi-View Display – Easily connect two CS1642A/1644A's units for a second dual-screen setup controlled through a single connection
- Superior video quality – 2560 x 1600 at 60Hz (DVI Dual link); and 3D displays up to 1920 x 1200 at 120Hz (DVI Single link)
- Supports widescreen resolutions
- Independent switching of KVM, USB, and Audio focus
- DVI digital and analog monitor support – fully compliant with DVI specifi cations; and HDCP compliant
- Multiplatform support – Windows 2000/XP/Vista, Linux, Mac, Sun, and FreeBSD
- Sun/Mac keyboard support and emulation
- Video DynaSync, exclusive ATEN technology, to eliminate boot-up display problems and optimizes resolution when switching between ports
Package Contents
- 1x CS1644A 4-Port USB DVI Dual View KVMP™ Switch
- 8x Custom DVI-D Dual Link Cable Sets
- 1x Power Adapter
- 1x User Instructions
Spesifikasjoner
| Garanti (måneder) | 24 |
|---|---|
| Enhetstype | KVM / lyd / USB-svitsj - 4 porter - kaskademulighet |
| Utførelse | Stasjonær |
| Undertype | KVM |
| Porter | 4 x KVM/lyd/USB |
| Antall lokale KVM-brukere | 1 lokalbruker |
| Tastatur/mus-grensesnitt | USB |
| Maks kaskadedybde | 3 |
| Maks. oppløsning | 2560 x 1600 @ 60 Hz |
| Egenskaper | Oppgraderbar fastvare, innbygd 2-porters USB 2.0-hub, Video DynaSync, 3D-støtte, nVidia 3D Vision-klar |
| Statusindikatorer | Strøm, status, USB, operasjonsmodus, lyd |
| Grensesnitt | 4 x tastatur (USB) / mus (USB) Type B 4 x mikrofoninngang mini-jack 4 x lydutgang mini-jack 8 x DVI-I (dual link) 1 x tastatur (USB) Type A 1 x mus (USB) Type A 1 x mikrofoninngang mini-jack 1 x lydutgang mini-jack 2 x DVI-I (dual link) 2 x USB 2.0 Type A 1 x kaskade RJ-45 |
|---|
| Strømenhet | Ekstern strømadapter |
|---|---|
| Strømforbruk ved drift | 12.19 watt |
| Medfølgende kabler | 8 x DVI-kabel |
|---|---|
| Tilpassede standarder | RoHS, WEEE, FCC Part 15 A |
| OS påkrevd | SunSoft Solaris, Apple MacOS, FreeBSD, Linux Kernel 2.6 eller nyere, Microsoft Windows Vista / 2000 / XP |
|---|
| Bredde | 43.24 cm |
|---|---|
| Dybde | 15.41 cm |
| Høyde | 4.4 cm |
| Vekt | 2.32 kg |
| Min. driftstemperatur | 0 °C |
|---|---|
| Maks. Driftstemperatur | 50 °C |
| Driftsfuktighet | 0 - 80% (ikke-kondenserende) |
| Min. oppbevaringstemperatur | -20 °C |
| Maks. oppbevaringstemperatur | 60 °C |
