HPE DL20 Server

Gen10 E-2224 1P 16G 2LFF Svr

Varenummer: 1160229 / Produktnr.: P17079-B21

Flere bilder av HPE DL20 Server

11 990,-
Fri frakt
eller
med ditt lagrede kort
med gebyrfri faktura Se fakturavilkår
7 stk. på lager.
Betal med
Fri frakt over 1000 kr
Retningslinjer for produktanmeldelser

HPE DL20 Server

HPE ProLiant DL20 Gen10 Server

  • Enterprise-class capabilities in a compact dense server.
  • Security innovations from Hewlett Packard Enterprise and Intel (SGX) provide your teams a secure platform.
  • Outstanding configuration flexibility caters to a wide variety of requirements at an affordable price point.
  • HPE InfoSight for Server brings artificial intelligence to HPE servers.
  • Offers outstanding configuration flexibility with 6 SFF/2 LFF drives; 290W, 500W, 800W 48 VDC redundant power supply; FlexibleLOM; and PCIe slots.

The dense and compact HPE ProLiant DL20 Gen10 Server powered by Intel® Xeon® E Processor, Pentium and Core i3 processors provides a unique blend of enterprise class capabilities & value. It offers outstanding configuration flexibility to cater to a wide variety of business requirements at an affordable price point. Deploy this dense platform for diverse workloads in space constrained environments and maintain it with ease by automating the most essential server lifecycle management tasks with HPE iLO 5.

HPE ProLiant DL20 Gen10 server is a flexible and affordable rackmount server ideal for focused hybrid cloud environment and key workloads—from core small office needs like collaboration and file/print to advanced edge applications for service providers—all in a space-saving 1U 15-inch chassis.

What's new?

  • Latest Intel® Xeon® E2200 up to 8 cores
  • 2666 MT/s HPE DDR4 Standard Memory UDIMM offering 8 GB, 16 GB; maximum 64 GB memory capacity supported
  • Enhanced storage: Up to 6 SFF drives and optional M.2 SSDs for boot
  • M.2 NVMe SSD onboard support
  • Dedicated HPE iLO port and serial port option kit
  • Redundant power supplies (500W and 800W 48 VDC) options
  • Support for Intel® Software Guard Extensions (SGX)
  • HPE InfoSight for Servers

Generelt
Garanti (måneder) 36
Type Server
Produktformfaktor Rackmonterbar - 1U
Serverskalerbarhet 1-veis
Prosessor / Chipset
CPU Intel Xeon E-2224 / 3.4 GHz
Max Turbo-hastighet 4.6 GHz
Antall kjerner Firerkjerne
Antall CPU-er 1
Maks. antall CPU-er 1
CPU-oppgraderbarhet Kan oppgraderes
Brikkesett type Intel C242
Cache-minne
Installert størrelse 8 MB
Cache pr. prosessor 8 MB
RAM
Installert størrelse 16 GB / 64 GB (maks.)
Teknologi DDR4 SDRAM - ECC
Virkelig minnehastighet 2666 MHz
Nominell minnehastighet 2666 MHz
Minnespesifikasjonkrav PC4-21333
Produktformfaktor DIMM 288-pin
Spor 4 (Total)
Egenskaper Ikke-bufret
Harddisk
Type Uten HDD
Diskkontroller
Type 1 x RAID
Kontroller grensesnittype SATA 6Gb/s
Lagringskontrollernavn HPE Smart Array S100i SR Software RAID
Kanal antall 4
RAID-nivå RAID 0, RAID 1, RAID 5, RAID 10
Optisk lagring
Type Ingen optisk drev
Skjerm
Skjermtype Ingen.
Grafikk-kontroller
Grafikkprosessor Matrox G200
Videogrensesnitt VGA
Nettverkstilknytning
Grensesnitts(databuss)-type PCI Express x2
Ethernet-porter 2 x Gigabit Ethernet
Ethernet-kontroller HPE 332i
Datakjedeprotokoll Ethernet, Fast Ethernet, Gigabit Ethernet
Fjernstyringskontroller Integrated Lights-Out 4
Egenskaper Wake on LAN (WoL), PXE-støtte
Tilpassede standarder IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Ekspansjon / Tilkoplinger
Brønner 1 (total) / 1 (ledig) x ekstern 5.25"
2 (total) / 2 (ledig) x intern 3.5" LFF
Spor 1 (total) / 1 (ledig) x PCIe 3.0 x16 - full lengde, full høyde (x16-modus)
1 (total) / 1 (ledig) x PCIe 3.0 x8 - lavprofils (x8-modus)
Grensesnitt 1 x VGA
1 x LAN (Gigabit Ethernet)
1 x LAN (Gigabit Ethernet) / HP iLO
5 x USB 3.0 (2 foran, 2 bak, 1 intern)
Diverse
Tilpassede standarder AES, FIPS 140-2, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, ACPI 6.1, Redfish API, UEFI
Strømforsyning
Enhetstype Strømforsyning
Installert antall 1
Nominell spenning AC 120/230 V (50/60 Hz)
Strømtilførsel 290 watt
Størrelser og vekt
Bredde 43.46 cm
Dybde 38.22 cm
Høyde 4.32 cm
Vekt 7.88 kg
Miljøparametere
Min. driftstemperatur 10 °C
Maks. Driftstemperatur 35 °C
Driftsfuktighet 8 - 90 % (ikke-kondenserende)
